Aidi Converged Communication Video Access Gateway V64

Eddie AD-V64 series: It is a convergent communication access gateway for 64 channels of video, complete interface design, excellent video and audio performance, and excellent network adaptability, bringing a perfect video experience; using the current H. 265 video compression technology, through GBT28181, ONVIF, SIP, H232 and other protocols to integrate video conferencing, video surveillance, emergency broadcast and other communication methods. Compatible with major brands of network cameras, using an independent encryption secondary compression algorithm to achieve full HD 1080P upload to the cloud, it has excellent features such as low latency, high definition, less bandwidth, automatic repair of disconnections, and automatic remote upgrades. And through the physical isolation of dual network ports, the transcoded video is safely connected to the public security platform or third-party platform for docking.

Details

1. Features


  • Dedicated ARM chip, embedded Linux equipment, stable and reliable, easy to maintain;

  • With video surveillance access function, support GB/T28181-2011 and GB/T28181-2016D standard surveillance platform, NVR, network camera access, support resource catalog management, video management, real-time monitoring, alarm access;

  • Support ONVIF camera access;

  • Support RTSP camera access;

  • Support RTMP camera access;

  • Support the emergency broadcast function, support the upper-level platform to broadcast to it, and support the gateway to broadcast to the lower-level IP sound column;

  • Support video broadcasting function, support the upper-level platform to broadcast video to it;

  • With video conferencing terminal function, support two-way video call;

  • Provide standard GB/T28181-2011/2016 interface to the superior for interconnection and mutual control;

  • Provide RTSP and HLS live streaming interface to access the real-time video of the connected camera;

  • Provide a special route mapping function, which can map the lower-level NVR and DVR to the upper-level network to facilitate the access control of the upper-level platform and isolate the two networks at the same time;
